Application:
- ISUZU FTR 26 foot box truck also called box vehicle, cargo truck, cargo van, box van, cube truck, lorry van, box truck is used to transport cargo with closed box. It is a very normal and important transport truck.
- The material used for van truck body could be corrugated steel, color steel plate, fiberglass, aluminum, or Stainless steel
- By adding a cooling system and polyurethane insulation layer, van trucks could be refrigeration trucks and carry cargo or food that need to be in low temperature.
- According to the requirements, it could be a single door at the rear or side or a double door.
ISUZU FTR 26 foot box truck Advantage:
- ISUZU FTR chassis, perfect performance
- ISUZU engine, super powerful; reliable performance, no overhaul within 500,000 km.
- Accept customized
- Free logo and box paint
- Euro IV, Euro V, Euro VI engine
Specification:
| Truck type | ISUZU FTR 26 foot box truck for sale |
| Driving Type | Left Hand Drive |
| Overall Dimension（L*W*H） | 10300X2550X3900mm |
| Box Dimension（L*W*H） | 8000X2450X2530mm |
| GVW | 16000Kg |
| Curb Weight | 7510Kg |
| Axle loading: | |
| Wheelbase | 5800mm |
| F/R Track | 1960/1855 |
| Approaching Angle/Departure Angle(o) | 15/13 |
| Tire No. | 7（Including Spare Tire） |
| Tire | 10.00R20 16PR |
| Color: | Optional |
| Max Speed（Km/h） | 105km/h |
| Engine | |
| Engine System | 4 Stroke, High-Pressure Common Rail, Inter-cooling Turbo-Charged, 4 Cylinders |
| Emission Route | DPF |
| Model | 4HK1-TC50 |
| Fuel Type | Diesel Engine |
| Max output | 150Kw |
| Horsepower： | 205Hp |
| Max Torque | 650N.m |
| Emission Standard | Euro V |
| Displacement: | 5193ml |
| Transmission: | |
| Model: | MLD-6Q |
| Type | Manual |
| Forward/Reverse | 6F/1R |
| Brake System: | |
| Service Brake | Dual Circuit Compressed Air Brake |
| Parking Brake | Spring Energy, Compressed Air Operating on Rear Wheels |
| Auxiliary System | Engine Exhaust Brake |
| Electrical System | |
| Battery | 2*12-70Ah |
| Alternator | 28V-70Ah |
| Starter | 24V/7.5Kw |
| Cab | |
| One Row and Half Cab with Air Conditioner | |
| Other Equipment: | |
| Power Steering, ABS, Maintenance Free Battery, Retro-reflective marking，Data Recorder，Vehicle Speed Light | |
Technical training support:
Truck Tools：
- Free parts for 12 months.
- Supply of original parts.
- DHL serves 7 days worldwide.
Factory Advantage:
- 16 years of design and export experience.
- 100% customized trucks.
- Quick delivery guarantee.
Export Documents:
- Serving more than 80 countries and regions.
- Professional guidance on import documents.
- CO, FORM E, FORM P, pre-implantation inspection
Truck shipping：
- Maximize your shipping costs.
- Professional guidance on import documents.
- Safe, fast and timely
Bulk order case:
- Fast shipping to all parts of the world.
- The truck color and logo can be customized.
