4WD Isuzu pickup mini water mist fire truck Description:
- 4WD Isuzu pickup mini water mist fire truck also called fire fighting tanker, fire appliance, fire fighting engine, fire-extinguishing water truck, service truck, fire rescue truck, fire engine, fire tender, fire vehicle, fire fighting equipment, fire fighting foam tanker.
- This fire truck is designed primarily for fire fighting operations – to extinguish fire efficiently to prevent fire spread, reducing the loss caused by fire maximally.
- Fire fighting trucks types: Water fire truck, foam fire truck, Dry powder fire fighting truck, Emergency rescue fire truck, equipment fire truck and more.
- Application: Urban public fire brigade, Petroleum chemical industry, textile enterprise, cigarettes factory, ports, docks, forest and other departments.
- According to the fire agent, there are water tank fire fighting trucks, dry powder fire fighting trucks, water/foam fire fighting trucks.
Advantage:
- 100% custom-made
- ISUZU Pickup Chassis, Durable & Performance.
- ISUZU engine & gearbox, super-powerful, no overhaul within 500,000 km.
- High-performance fire pump and fire cannon
- Water tank and Foam tank capacity can be optional.
- Tanker material: Carbon steel or Stainless steel
- With a complete set of fire fighting Accessories & Equipment, your can put in work immediately.
- Easy operation and easy maintenance.
- FREE training in our factory if you need it.
Specification:
| vehicle | vehicle name | 4WD Isuzu pickup mini water mist fire truck for sale Philippines | |||
| Dimensions | 5230×1670×2360(mm) | ||||
| total mass | 3390 kg | ||||
| curb weight | 2420kg | ||||
| Load quality | 820kg | ||||
| number of passengers | 2 people | ||||
| approach/departure angle | 21/17 (°) | ||||
| chassis | brand | ISUZU TAGA | |||
| Chassis model | QL1035SJ16QC | ||||
| cab | double cabin | ||||
| wheelbase | 2600mm | ||||
| engine | 141 hp | ||||
| Emission Standards | Euro VI | ||||
| gearbox | 5th gear with double cone synchronizer | ||||
| tire | 175R14LT | ||||
| other | Hydraulic power assist/multi-function steering wheel/LCD instrument panel/electric window/central lock/air conditioner/MP5/Bluetooth phone/fixed belt cruise/LED daytime running lights/rearview mirror electric adjustment + electric heating | ||||
| special function | liquid tank | Liquid capacity | Water 920kg Fire extinguishing agent 80kg | ||
| material | High-strength high-quality stainless steel | ||||
| Fire Pump | model | Italy RTX 70-200 high pressure plunger pump | |||
| installation location | rear | ||||
| flow | 60L/min | ||||
| greatest pressure | 20MPa | ||||
| Rated speed | 1450rpm | ||||
| power | Chassis Engine Provided | ||||
| link hose | 75M (fixed) + 25M (portable reel) | ||||
| Power take-off and transmission system | structure type | Sandwich type mechanical transmission | |||
| Clutch mode | hand control | ||||
| Lubrication method | splash lubrication | ||||
| transmission system | cross shaft universal joint drive shaft | ||||
| Pipeline system | Inlet pipe | DN50 ball valve control | |||
| High pressure water outlet pipe | Pressure 20MPa | ||||
| High pressure return pipe | Pressure 20MPa | ||||
| water injection line | 1 Φ65mm water injection port | ||||
| Mobile high pressure reel | 2 | ||||
| Multifunctional spray gun | model | QMX10/60-WTL | |||
| jet form | DC, water mist | ||||
| range | DC state | Water mist state | |||
| ≥15m | ≥9m | ||||
| lighting equipment | 360°lift lighting | model | Wilbur 24-LED | ||
| power | 80W（LED） | ||||
| lift height | 3.5m (off the ground) | ||||
| Voltage | 12V | ||||
| control method | remote control | ||||
| Other lamps | Police lights/Sirens/Marker lights/Position lights | ||||
| Ladders and Ladder Frames | material | aluminum alloy | |||
| Extended height | 4 meters | ||||
| ＊Note: This parameter is the standard configuration of the manufacturer and can be customized according to customer needs. | |||||
ISUZU Fire fighting vehicle Bodywork details:
Fire equipment table:
| Serial number | name | specification | Quantity | unit | Remarks |
| 1 | straw | 125×4 meters | 2 | root | Threaded |
| 2 | Water filter | FLF125 | 1 | Piece | Threaded |
| 3 | Trap | FII80/65×3-1.6 | 1 | Piece | Internal button |
| 4 | Water trap | JII125/65×2-1.0 | 1 | Piece | Internal button |
| 5 | Hose | 13-65-20 | 6 | plate | Low pressure; |
| 6 | Hose | 13-80-20 | 6 | plate | Low pressure; |
| 7 | Reducing interface | KJ65/80 | 2 | Piece | Internal button |
| 8 | Water-retaining cloth | DT-SB | 4 | Piece | Internal button |
| 9 | Hose hook | 4 | Piece | ||
| 10 | Ground fire hydrant wrench | QT-DS1; length 400 | 1 | Piece | |
| 11 | Underground hydrant wrench | Long 860 | 1 | Piece | |
| 12 | Suction pipe wrench | FS100 | 2 | Piece | |
| 13 | DC switch water gun | QZG3.5/7.5; 65 | 1 | support | Low pressure; |
| 14 | DC Flowering Water Gun | QZK3.5/7.5; 65 | 1 | support | Low pressure; |
| 15 | Fire extinguisher | 3KG | 1 | With | |
| 16 | Fire waist axe | Length 390; GF-285 | 1 | Piece | |
| 17 | Rubber hammer | 1 | Piece | ||
| 18 | Rechargeable portable lighting | 1 | Piece |
Optional fire equipment:
| Serial number | name | specification | Quantity | unit | Remarks |
| 1 | Automatic charging device | 12V | 1 | set | |
| 2 | Air backrest | 3 | set | ||
| 3 | Air breathing apparatus | Number of members | set | ||
| 4 | Hose bridge | rubber | 2 | vice | |
| 5 | Telescopic ladder | 1 | vice | ||
| 6 | Hand lift the pump | 1 | station | ||
| 7 | Breaking tools | 1 | set | ||
| 8 | Other fire equipment |
fire fighting engine Parts Picture：
Factory Advantage:
- 17 years of design and export experience.
- 100% customized trucks.
- Quick delivery guarantee.
Documents:
- Serving more than 80 countries and regions.
- Professional guidance on import documents.
- CO, FORM E, FORM P, pre-implantation inspection
