[Technical parameters of the vehicle]

product name

CL5180GSSBEV 4000 gallon water truck

Total mass(kg)

18000

Tank volume(m3)

16

Rated mass(kg)

7720

Dimensions(mm)

9140X2550X3055

Curbweight (kg)

10150

Cargo compartment size(mm)

XX

The number of passengers in the cab(person)

2

Maximum load of saddle(kg)

Approach angle/departure angle (°)

16/12

Front suspension/rear suspension (mm)

1370/2520

Axle load(kg)

7000/11000

Maximum speed(km/h)

85

Remark:

Remarks:1. The main special devices for vehicles are tanks, water pumps, waterway systems and control systems, which are mainly used to clean the urban environment and spray water on the road to reduce dust.

Industry; 2. The effective volume of the tank is16cubic meters, and the overall dimensions of the tank (long axis × short axis × length) (mm): 2300 × 1280

×4100, the shipping medium is an aqueous solution, and the density of the medium is 1000Kg/m3; 3.The material of the side protection device: aluminum alloy, and the vehicle

Connection method: bolt connection; rear guard material: 16MnREL, connection method with vehicle: bolt connection, rear guard section size:

189mm×77mm, the height from the ground is 500mm; 4. The type of energy storage device of this car is lithium iron phosphate lithium ion power battery, model

/Manufacturer: C105L-3P32S/Nanjing Chuangyuan Tiandi Power Technology Co., Ltd., monomer model/Manufacturer: LF10

5 / Huizhou Yiwei Lithium Energy Co., Ltd.; 5. Drive motor model / manufacturer: TZ370XS-LKM1302/Su

Green Control Transmission Technology Co.,Ltd., rated power 120kW, peak power 185kW; 6.ABS model: APG35

50500H1, manufacturer: Zhejiang Asia-Pacific Mechanical and Electrical Co., Ltd.; 7. Equipped with a driving recorder with satellite positioning function.

【Chassis technical parameters】

Chassis model

QL1180BEVEKMHY

Chassis name

Pure electric truck chassis

Trade name

Qingling Brand(Traditional) Brand

manufacturer

Qingling Motors Co., Ltd.

Number of axes

2

Number of tires

6

Wheelbase(mm)

4600

Tire specifications

315/80R22.5 20PR

Number of leaf spring

4/4+3

Front track(mm)

2065

Fuel type

Pure electric

Rear track(mm)

1855

Emission standard

engine model

Engine manufacturer

engine capacity

Engine power

TZ370XS-LKM1302

Suzhou Green Control Transmission Technology Co., Ltd.

0

185
